Bike Specifications
Technical Details
Engine
PRIMARY DRIVE
36:79
TORQUE
73 Nm
TRANSMISSION
6-speed
BATTERY CAPACITY
8.6 Ah
COOLING
Liquid cooled
SECONDARY GEAR RATIO
15:46
POWER IN KW
58.1 kW
POWER
79 PS
STARTER
Electric starter
STROKE
80 mm
BORE
105 mm
CLUTCH
PASC slipper clutch, hydraulically operated
CO₂ EMISSIONS
98 g/km
COMPRESSION RATIO
12.7
DISPLACEMENT
692.7 cm³
EMS
Keihin EMS with RBW, twin ignition
DESIGN
1-cylinder, 4-stroke engine
FUEL CONSUMPTION
4.3 l/100 km
FUEL-MIXTURE GENERATION
Keihin EFI (throttle body 50 mm)
LUBRICATION
Pressure lubrication with 1 oil pumps
Chassis
WEIGHT (WITHOUT FUEL)
152 kg
TANK CAPACITY (APPROX.)
13.5 l
WHEELBASE
1506 mm
FRONT BRAKE DISC DIAMETER
300 mm
REAR BRAKE DISC DIAMETER
240 mm
FRONT BRAKE
Brembo twin-piston floating calliper, brake disc
REAR BRAKE
Brembo single-piston floating calliper, brake disc
CHAIN
520 X-Ring
FRAME DESIGN
Chromium-Molybdenum steel trellis frame, powder coated
FRONT SUSPENSION
WP XPLOR-USD, Ø 48 mm
GROUND CLEARANCE
265 mm
HANDLEBAR
Aluminium, tapered Ø 28/22 mm
REAR SUSPENSION
WP XPLOR with Pro-Lever linkage
SEAT HEIGHT
935 mm
SILENCER
Stainless steel primary and secondary silencer
STEERING HEAD ANGLE
62.3 °
REAR SUBFRAME DESIGN
Self-supporting plastic tank
SUSPENSION TRAVEL (FRONT)
265 mm
SUSPENSION TRAVEL (REAR)
250 mm
TYRE DIMENSIONS (FRONT/REAR)
90/90; 140/80
WHEELS
1.85 x 21"; 2.50 x 18"
WHEELS
Spoked wheels with aluminium rims
WHEELBASE
1506 ± 15 mm
