Bike Specifications
Technical Details
Engine
PRIMARY DRIVE
39:75
TORQUE
100 Nm
TRANSMISSION
6-speed
BATTERY CAPACITY
10 Ah
COOLING
Liquid cooled with water/oil heat exchanger
SECONDARY GEAR RATIO
16:45
POWER IN KW
77 kW
STARTER
Electric starter
STROKE
68.8 mm
BORE
90.7 mm
CLUTCH
Cable operated PASC slipper clutch
CO₂ EMISSIONS
103 g/km
COMPRESSION RATIO
13.5
DISPLACEMENT
889 cm³
EMS
Bosch EMS with RBW
DESIGN
2-cylinder, 4-stroke, parallel twin
FUEL CONSUMPTION
4.5 l/100 km
FUEL-MIXTURE GENERATION
DKK Dellorto (Throttle body 46mm)
LUBRICATION
Forced oil lubrication with 2 oil pumps
Chassis
WEIGHT (WITHOUT FUEL)
214.5 kg
TANK CAPACITY (APPROX.)
19 l
WHEELBASE
1,529 mm
FRONT BRAKE DISC DIAMETER
320 mm
REAR BRAKE DISC DIAMETER
260 mm
FRONT BRAKE
2 x 4-piston caliper, radially mounted, brake disc
REAR BRAKE
2 piston floating caliper, brake disc
CHAIN
520 X-Ring
FRAME DESIGN
Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
FRONT SUSPENSION
WP XPLOR-USD, Ø 48 mm
GROUND CLEARANCE
270 mm
HANDLEBAR
Aluminium, tapered Ø 28/22 mm
REAR SUSPENSION
WP XPLOR-Monoshock
SEAT HEIGHT
887/907 mm
SILENCER
Stainless steel primary and secondary silencer
STEERING HEAD ANGLE
64.2 °
REAR SUBFRAME DESIGN
Chromium-Molybdenum-Steel trellis, powder coated
SUSPENSION TRAVEL (FRONT)
240 mm
SUSPENSION TRAVEL (REAR)
240 mm
WHEELS
2.50 x 21"; 4.50 x 18"
WHEELS
Spoked wheels with aluminium tubeless rims
WHEELBASE
1,529 ± 15 mm
