Bike Specifications
Technical Details
Engine
PRIMARY DRIVE
39:75
TRANSMISSION
6-speed
COOLING
Liquid cooled with water/oil heat exchanger
SECONDARY GEAR RATIO
16:41
POWER IN KW
77 kW
STARTER
Electric starter
STROKE
65.7 mm
BORE
88 mm
CLUTCH
Cable operated PASC slipper clutch
CO₂ EMISSIONS
106 g/km
COMPRESSION RATIO
12.5
DISPLACEMENT
799 cm³
EMS
Bosch EMS with RBW
DESIGN
2-cylinder, 4-stroke, parallel twin
FUEL CONSUMPTION
4.5 l/100 km
FUEL-MIXTURE GENERATION
DKK Dellorto (Throttle body 46mm)
LUBRICATION
Pressure lubrication with 2 oil pumps
Chassis
WEIGHT (WITHOUT FUEL)
180 kg
TANK CAPACITY (APPROX.)
13.7 l
WHEELBASE
1.475 mm
ABS
Bosch 9MB Two Channel ABS (disengageable)
FRONT BRAKE DISC DIAMETER
300 mm
REAR BRAKE DISC DIAMETER
240 mm
FRONT BRAKE
2 x 4-piston caliper, radially mounted, brake disc
REAR BRAKE
1 Piston Floating caliper, brake disc
CHAIN
520 X-Ring
FRAME DESIGN
Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
FRONT SUSPENSION
WP APEX-USD, Ø 43 mm
GROUND CLEARANCE
170 mm
HANDLEBAR
Aluminium, tapered Ø 28/22 mm
REAR SUSPENSION
WP APEX - Monoshock
SEAT HEIGHT
838 mm
SILENCER
Stainless steel primary and secondary silencer
STEERING HEAD ANGLE
65.5 °
REAR SUBFRAME DESIGN
Cast aluminium, powder coated
SUSPENSION TRAVEL (FRONT)
140 mm
SUSPENSION TRAVEL (REAR)
150 mm
TYRE DIMENSIONS (FRONT/REAR)
Variable by market
WHEELS
3.5 x 17"; 5.5 x 17"
WHEEL TYPE
Cast aluminium wheels
WHEELBASE TOLERANCE
1.475 ± 15 mm
